AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester

AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
AT3010 AC50~320V 100A 3KKW Phone App AC Digital Voltage Meters indicator Power Energy Meter Voltmeter Ammeter Current Amps Volt Wattmeter Tester
  • Stock: In Stock
  • Model: ST22012221
  • Dimensions: 10.00cm x 11.00cm x 18.50cm
  • SKU: ST22012221
$20.99
Ex Tax: $20.99

Available Options


Description:
bluetooth Version and Standard Version(optional)

AT3010 AC meter electrical parameter:


Voltage measurement range: 050.0V~320V Resolution accuracy: 0.1V
Current measurement range: 0.000A~100.0A Resolution accuracy: 0.001A
Power measurement range: 0000.0W~99999.9W Resolution accuracy: 0.1W
Power accumulation range: 00000.00 degrees ~99999.9 degrees (KWh) Resolution accuracy: 0.01 degrees
The total range of electricity charges: 00000.00~42000000.00 $ Resolution accuracy: 0.01 yuan or other countries
Electricity price setting range: 0000.00~9999.99 $ Resolution accuracy: 0.01 yuan or other country
Carbon dioxide range: 000.00~9999.99Kg (KWh*997/1000 5/3 bit switch)
Temperature measurement range: 0~99 degrees Celsius 0~99°C Resolution accuracy: 1 degree Celsius
Standby power consumption: <0.5W~1W
Refresh time: >500mS/time> 500mS/time
Measurement rate: about 0.5 times / sec
Display type: micro-power LCD module LCM black font green backlight Chinese and English display
Product size: 117 x 61 x 38mm
Working temperature: -10~+60 degrees Celsius -10~+60°C
Working humidity: 10~80 (no doubt exposed) 10~80 (no doubt)
Working pressure: 80~106kPa


100A 300V DC Energy Meter Energy Monitoring (bluetooth Version and Standard Version optional )

Package Includes:

1 x AT3010 AC meter
1 x User Manual


Detials Pictures:



AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-1
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-2
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-3
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-4
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-5
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-6
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-7
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-8
AT3010-AC50320V-100A-3KKW--Phone-App-AC-Meters-Digital-Voltage-Meters-indicator-Power-Energy-Meter-V-1390443-9
