0.36 Inch 3-in-1 Time + Temperature + Voltage Meter Display with NTC DC7-30V Voltmeter Electronic Watch Clock Digital Tube
- Stock: In Stock
- Model: ST230043706
- SKU: ST230043706
$13.99
Ex Tax: $13.99
Feature:
Reverse does not burn, the number does not shake
Digital tube: 36 x 14 x 13mm (L x W x H)
Board: 35 x 16mm
Power supply: 7-30V, high brightness LED digital tube
Color: red, blue, green, yellow (optional)
4 display modes: 1: Display time only 2: Display temperature only 3: Display voltage only 4: Time temperature voltage is alternately displayed.
Note:
1. The difference between 33v and 200v is that the maximum measurement voltage is different. Car battery 12v can select 33v, and electric vehicle can select 200v.
2. Three-in-one table temperature sensor line defaults 1 meter, can not be extended, will affect the accuracy of time after extension, please think twice.
| Voltage |
R ange: 0-33V, error +-0.02V R ange: 0-200V, error +-0.1V Power supply 7-30V. Two r anges are available. |
| Temperature | -50 ° C ~ 125 ° C, NTC probe, extension line 1 m, waterproof. Accuracy 0.0625, no calibration required. |
| Time | 24-hour system, clock chip accuracy of 15ppm, with power off memory function, accurate time. |
Key setting:
Button 1:
Short press to select the clock, second, voltage, temperature display mode;
Press and hold to display ALL, enter the time---voltage---temperature tracking mode, with an interval of 5 seconds. Press the button again to exit the mode.
Button 2:
Short press to adjust time, minute (flashing), and press one button to adjust. Press button 2 again to exit the adjustment mode.
Remarks: Adjust “minutes”, the clock will stop after exiting, and press the button to start walking.
Package includes:
1 x Voltmeter
