ZK-XPS 150Wx2 2.0 Dual Channel Stereo TDA7498E Bluetooth Audio Power Amplifier Board Module
- Stock: In Stock
- Model: ST230043886
- SKU: ST230043886
$23.99
Ex Tax: $23.99
Features:
1: Widely used
2: Adopt TDA7498E chip scheme
3: Output with filter, HIFII sound quality
4: Heat sink heat dissipation, super power.
5: Undervoltage, overheating, overcurrent, short circuit protection
Specification:
Product name: 2.0 channel Bluetooth audio power amplifier module
Bluetooth version: 5.0 (unobstructed, 15 meters)
Input method: AUX＋Bluetooth
Number of channels: 2.0 channels (left channel + right channel)
Amplifier chip: TDA7498E
Adapter power supply: DC 12~32V (under voltage protection below 9V, 12V power supply can also be supported)
Adapted speakers: 30-200W, 4-8Ω
Output power: left and right channels ≤150W
Protection mechanism: under voltage, over heat, over current, short circuit protection
Product size: 110 x 58 x 25mm
Net weight: 109g
Packaging weight: 143g
Note:
When the audio signal input is large enough and the power supply voltage/current is large enough, there will be enough Output Power!
The higher the power supply voltage, the greater the output power, and the smaller the speaker impedance, the greater the output power! Please make sure that the power of the adapter is greater than the actual working power of the amplifier!
Package included:
1 x Power amplifier board module
