FNB18 32V 160W USB3.0 Tester DC Digital Voltmeter Amperimeter Current Voltage Amp Volt Ammeter Detector Power Bank Charger Indicator with Color Screen
- Stock: In Stock
- Model: ST22011710
- SKU: ST22011710
$13.99
Ex Tax: $13.99
Features:
Adopting 8192 pixels true color screen LCD HD display.
Fully powered off, timing shutdown, multi-screen design, precise measurement, wide voltage, low internal resistance.
You can switch between different test content interfaces by short pressing the multi-function button.
Summarize a variety of large-scale instruments and use precise devices to develop, voltage up to 32V, power up to 160W, other industrial high-voltage power supply and fast charge voltage range measurement.
Compatible with USB3.0 device and compatible with USB2.0, support high current test, wide range of uses.
General test 3C digital peripheral products, such as USB recharger, power bank, electronic load, USB light and 3.0U disk, etc.
Added V+, D-, D+, V- four-wire voltage full detection interface to meet the handshake state and electrical parameter measurement when adapting to mobile phone charging.
Overvoltage protection, overcurrent protection, low voltage protection, low energy protection, alarm prompt.
Power-off memory technology, storage for ten years.
Use USB3.0 color screen monitor to safely charge mobile phone, monitor charging data in real time, support QC3.0 (3.8-12V, +/-0.2 step) and support QC2.0 (5V/9V/12V/20V), Android BV1.2 (5V), ios 5V/2.4A and MTK-PE (5V/7V/9V/12V) and other high-pass fast charging voltage range charging pass-by measurement, easy and safe to measure.
Specifications:
Material: ABS
Color: black
Measurement ranges (and resolution accuracy):
Voltage: 3.60-32.0V (0.01V)
Current: 0.00-5.00A (0.01A)
Capacity accumulation: 0–99999mAh (0.001Ah)
Power accumulation: 0–9999.99Wh (0.01Wh)
Power calculation: 0.00-160.00W (0.01W)
Impedance: 0.0- 6000.0Ω (0.1Ω)
Temperature: 0-100℃ (1℃)
Timing time: 999H59M59S (1S)
USB D+ voltage: 0-3.30V (0.01V)
USB D- voltage: 0-3.30V (0.01V)
Input interface: USB
Output interface: USB
Timed charge reminder settings: 24-hour countdown
Full charge threshold parameters: < 2W / 0.5hours
Refresh time: > 500mS / time
Measurement rate: about 0.5 time / S
Alarm mode: siren sound
Display type: micro-power LCD module LCM white font
Current consumption: < 0.02A
Operating temperature: -10 to +60℃
Working humidity: 10 to 80 (no frost)
Work pressure: 80-106Kpa
Item size: 76 * 30.5 * 15.6mm / 3.0 * 1.2 * 0.6in
Package size: 85 * 40 * 20mm / 3.3 * 1.6 * 0.8in
Package weight: 23.35g / 0.8ounce
Package included:
1 * USB Multifunctional Tester
Details pictures:
