NPS-1601 0-32V 0-5A 110V/220V 160W Switching Digital Adjustable DC Power Supply
- Stock: In Stock
- Model: ST220016488
- SKU: ST220016488
$80.49
Ex Tax: $80.49
Description:
GOPHERT NPS-1601 0-32V 0-5A 110V/220V 160W Switching Digital Adjustable DC Power Supply
Features:
GOPHERT NPS-1601 0-32V 0-5A 110V/220V 160W Switching Digital Adjustable DC Power Supply
Features:
Top performance cost ratio
High power density, smallest and compact
Aluminum shell, lower EMI.
Using Encoder to set the voltage and current.
Four digital volt and current meter.
Switchable 110V and 220V inputs.
- Output Terminal On The Front Panel, Use More Friendly
- Has Both Lock And Power Display Function (WATT)
- Voltage And Current Setting Selector Used Tack Switch Instead Of - Slide Switch, Improved The Relibility
- Setting And Reading Are More Accuracy,The Resolution of Amp meter is 1mA,Volt meter is 10mV
- Ripple & Noise (peak-peak) less than 10mV
- Zero overshoot (c.v mode and c.c mode),Protect sensitive device
- High efficiency >87%
- Intelligent protection: Output short circuit protection, Tracking Over Voltage Protection (OVP), Tracking Over Current Protection(OCP), Over Temperature Protection (OTP) SMT components: Reflow soldering process, higher relibility
Specification:
Model: NPS-1601 (32V 5A)
Operation Voltage Range:198 – 264Vac/100-144Vac
Operation Frequency Range:45 – 65HZ
Output Voltage Range:0 – 32V
Output Current Range:0 – 5A
Efficiency (220Vac/full load):≥ 87%
Full Load Input Current (220Vac):≤ 1.4A
No Load Input Current(220V):≤ 80mA
Volt Meter Accuracy:≤ 0.1% + 2 digit
Amp Meter Accuracy:≤ 0.1% + 3 digits
Plug: EU Plug (will provide adapter according to delivery country)
Plug: EU Plug (will provide adapter according to delivery country)
Constant Voltage
Load Regulation (0-100%):≤ 30mV
Line Regulation(198-264Vac/100-144Vac):≤ 5mV
Ripple & Noise (Peak-Peak):≤ 10mV
Ripple & Noise (r.m.s):≤ 2mV
Set Accuracy:≤ 0.3% + 10mV
Transient Response Time (50%-100% Rated Load):≤ 1.0ms
Constant Current
Load Regulation (90%-10% Rated Voltage):≤ 50mA
Line Regulation (198-264Vac/100-144Vac):≤ 20mA
Current Ripple & Noise (Peak-Peak):≤ 10mAp-p
Set Accuracy:≤ 0.2% + 3mA
Size(width* height* depth):120*50*180mm
Net Weight:0.8KG
Package includes:
1 x NPS-1601 DC Power Supply
1 x AC Power cable
1 x User Manual
