DC24V 48V 3.6KW 6.2KW Solar Inverter Pure Sine Wave Inversor PV Input Max DC 500V MPPT 120A Solar Controller

Model

POW-HVM3.6M-24V

POW-HVM6.0M-48V

update to

POW-HVM6.2M-48V

Phase

1-phase

Maximum PV Input Power

6000W/6200W

Rated Output Power

3600W

6000W update to 6200W

Maximum Charging Power

6000W/6200W

GRID-TIE OPERATION

PV Input(DC)

Nominal DC Voltage/Maximum DC Voltage

360VDC/500VDC

MPPT Voltage Range

120VDC~450VDC

GRID OUTPUT(AC)

Nominal Output Voltage

220/230VAC

Output Voltage Range

195.5-253VAC

Nominal Output Current

15.7A 26.1A

Power Factor

>0.9

EFFICIENCY

Maximum Conversion Efficiency(DC/AC)

97%

OFF-GRID OPERATION

AC INPUT

AC Start-up Voltage/Anto Restart Voltage

120-140VAC/180VAC

Acceptable Input Voltage Range

90-280VAC OR170-280VAC

PV Input(DC)

Nominal DC Voltage

500VDC

MPPT Voltage Range

120VDC-450VDC

BATTERY MODE OUTPUT(AC)

Nominal Output Voltage

24VDC/48VDC

Output Waveform

Pure sine wave

Efficiency(DC to AC)

94%

GENERAL

PHYSICAL

Dimension D *W *H

420*310*120 mm

Net Weight

10.5kg

11kg

INTERFACE

Communication Port

RS232(without WIFI)

ENVIRONMENT

Humidity

 0-90%
