RC-112 220V/110V 10A Digital LCD Thermostat Regulator Temperature Controller
- Stock: In Stock
- Model: ST220016779
- SKU: ST220016779
$23.99
Ex Tax: $23.99
Features :
A mini temperature controller.
With large and clear LCD display for better readability.
Wide temperature measuring range.
Heating and cooling control.
Temperature calibration function.
Delay protection function.
All parameters can be set to default setting after short circuit.
Can be used for domestic freezer, water tanks, refrigerator, industrial chiller, bolier, steamer, industrial equipments and other temperature-controlled systems.
Specifications :
Temperature measuring and controlling range : -40 - 99°C
Relay capacity of Compressor options : 10A
Power options : 220VAC, 110VAC Input : 1 NTC sensor; sensor wire : 2m(standard)
Accuracy : ±1°C; Resolution : 1°C
Consumption : ≤3W
Cut-out size : 71 x 29(mm)
Ambient requirements : temperature : -10 - 60°C; humidity : 20 - 85% (No condensate)
Package includes :
1 x RC-112 Temperature Controller (110V, 220V for optional~)
1 x 2M NTC sensor
1 x User manual
Contact us Download E-User Manual
Details pictures :
,
,
,
,
,
,
,
A mini temperature controller.
With large and clear LCD display for better readability.
Wide temperature measuring range.
Heating and cooling control.
Temperature calibration function.
Delay protection function.
All parameters can be set to default setting after short circuit.
Can be used for domestic freezer, water tanks, refrigerator, industrial chiller, bolier, steamer, industrial equipments and other temperature-controlled systems.
Specifications :
Temperature measuring and controlling range : -40 - 99°C
Relay capacity of Compressor options : 10A
Power options : 220VAC, 110VAC Input : 1 NTC sensor; sensor wire : 2m(standard)
Accuracy : ±1°C; Resolution : 1°C
Consumption : ≤3W
Cut-out size : 71 x 29(mm)
Ambient requirements : temperature : -10 - 60°C; humidity : 20 - 85% (No condensate)
| Code | Function | Setting range | Default | Unit |
| HC | Mode option | C : refrigeration H : heating | C | / |
| D | Controlling-temp. differential | 1 - 15 | 3 | ℃ |
| LS | Lower Temp.limit | -40 - settung Temp. | -40 | ℃ |
| HS | Upper Temp.limit | Setting Temp. - 99 | 99 | ℃ |
| CA | Temp. calibration | -5 - 5 | 0 | ℃ |
| PT | Compressor delay | 0 - 15 | 3 | Min |
Package includes :
1 x RC-112 Temperature Controller (110V, 220V for optional~)
1 x 2M NTC sensor
1 x User manual
Contact us Download E-User Manual
