STC Soldering Station 100-500℃ Degree OLED Display 4Pin Temperature Controll With Soldering Wire Iron Tips Welding Tools
- Stock: In Stock
- Model: ST22008345
- SKU: ST22008345
$44.25
Ex Tax: $44.25
Temperature-CAL:
0~500℃: Click to select the 100℃ to 500℃ option, the soldering iron will be heated according to the temperature table corresponding to the soldering iron tip number set in the "Tip Selection", and the heating will automatically stop after unchecking.
During the calibration process, if the actual temperature is lower than the set temperature, increase the AD value; if the actual temperature is higher than the set temperature, decrease the AD value. 0°C and 600°C are generally the default values without adjustment.
When calibrating the soldering iron tip, remember that this set of data must be strictly increased from small to large, otherwise the temperature is invalid. For example, if before calibration: 100℃, AD=110; 200℃, AD=270; 300℃, AD = 380, when calibrating 200℃, the temperature is less than 200℃, you need to increase the AD value from 270, but its size It cannot exceed the AD value of 380 at 300°C.
If the temperature cannot reach 200°C when the temperature is adjusted from 270 to 380, it means that the value of 380 at 300°C is also too small. You need to increase the 380 at 300°C first.
Package included:
1 x Handskit STC Soldering Station Kits
