- Stock: In Stock
- Model: ST22022895
- Dimensions: 1,180.00mm x 540.00mm x 3.30mm
- SKU: ST22022895
Specification:
Product size | 1180*540*3.3mm |
Power | 100W |
Working voltage | 18.1V±0.3V |
Working voltage | 16.1A±0.5A |
Temperature coefficient Voltage | (0.065±0.015)%/℃ |
Temperature coefficient current | -(160±10)mA/℃ |
Temperature coefficient power | -(0.5±0.05)%/℃ |
System voltage | 1000V |
Operating environment temperature | -40°C-+85°C (-40°F to 185°F) |
Wind resistance | 50psf (2400 pascals) |
Snow resistance | 113psf (5400 pascals) |
Hail impact | 25mm (1 inch) at 23 m/s (52mph) |
Warm Tips:
1.Please make sure the positive and negative terminals of this product are
connected with the charged product's positive and negative terminals before usage.
2.Please do not try to modify the PCB circuit unless you are a professional
technician.And we are not responsible for such a result.
3.The best working time: 9:00-17:00 (mainly for sunlight weather).
which is intended to extend the battery life and emergency charge usage.Please
choose other higher current products if you want a faster charging speed.
Package included:
1 x 100W Solar Panel
1 x Controller (10-30A)
Note:
1.Please don't scratch the surface of the solar panel with a sharps object.
2.Please make the solar panel exposed to direct sunlightto ensure the best charging speed while it is charging.
3.Please don't place the charger in the rainny day,or it will lead to a short circuit.
4.The 18V 300W solar panel charger is built with an Anti-flow resistense preventerinsdie,it will not occur the backflow phenomenon.
